Bicycle shelters


Only the best for your steel bike

Lucca is a multifunctional canopy with or without walls and a minimum number of columns. In addition, the canopy can be attached to an existing structure. This makes Lucca ideal as a bicycle shed. Furthermore, it can be combined with our bicycle racks and bicycle brackets and is equipped with an integrated rainwater drainage system.

/Technical data

  • Columns in square tube 80x80x3mm
  • Gutters in bended steel sheet 150x120x3mm
  • Beams in square tube 50x50x2mm
  • Connection beams in square tube 60x60x3mm
  • Drainage through the structure by means of outflow of rainwater via spouts
  • Delivered detached
  • Steel
  • Polyester skylight
  • Clear polycarbonate skylight (double-walled 10mm)
  • Solid clear skylight (thickness 3mm)
  • Clear tempered glass 8m
  • Open trellis of soaked pine wood
  • Open trellis of untreated hardwood


Lucca with fixed width 2120mm
  • LxWxH: 4130x2120x2250mm
  • LxWxH: 5910x2120x2250mm
  • LxWxH: 8210x2120x2250mm
  • LxWxH: 10250x2120x2250mm
  • LxWxH: 15350x2120x2250mm
Lucca with fixed width 4000mm
  • LxWxH: 4130x4000x2250mm
  • LxWxH: 5910x4000x2250mm
  • LxWxH: 8210x4000x2250mm
  • LxWxH: 10250x4000x2250mm
  • LxWxH: 15350x4000x2250mm
Lucca is custom made available

Surface treatment
  • Hot-dip galvanized steel
  • Hot-dip galvanized steel and powder coated steel
